MSI B450 GAMING PLUS MAX - Rear I;O Panel Overview; LAN Port LED Status Table; Audio Ports Configuration

8

Link/ Activity LED
Status Description
Off No link
Yellow Linked
Blinking Data activity
Speed LED
Status Description
Off 10 Mbps connection
Green 100 Mbps connection
Orange 1 Gbps connection
LAN Port LED Status Table

Audio Ports

2 4 6 8

    
Rear Speaker Out   
Center/ Subwoofer Out  
Side Speaker Out 
Mic In
Blank: empty)

PS/2
LAN

Audio Ports


USB 3.2 Gen2

Flash BIOS Button
y 
Button.
Flash BIOS Port
