16
Specifications
Continued from previous page
LAN ∙ 1x Realtek® 8111H Gigabit LAN controller
Wireless LAN &
Bluetooth®
∙ Wi-Fi/Bluetooth expansion module with Intel Single Band
Wireless-AC 3168 chip
∙ Supports Wi-Fi 802.11 a/b/g/n/ac, single band (2.4GHz,
5GHz) up to 433 Mbps speed.
∙ Supports Dual Mode Bluetooth 2.1, 2.1+EDR, 3.0, 4.0, BLE,
4.2
∙ 1x M.2_2 Socket with E key (Wi-Fi mode)
USB
∙ AMD® B450 Chipset
▪ 6x USB 3.2 Gen1 (SuperSpeed USB) ports (4ports on
the back panel, 2 ports available through the internal
USB connector)
▪ 8x USB 2.0 ports (4 ports on the back panel, 4 ports
available through the internal USB connectors)
Audio
∙ Realtek® ALC892 Codec
∙ 7.1-Channel High Definition Audio
Back Panel
Connectors
∙ 1x PS/2 keyboard/ mouse combo port
∙ 1x WiFi/ Bluetooth module
∙ 4x USB 2.0 ports
∙ 1x HDMI Port
∙ 4x USB 3.2 Gen1 Type-A ports
∙ 1x LAN (RJ45) ports
∙ 3x audio jacks
Continued on next page
