i
<󸙗󳽙 1> Regulatory Notices
FCC Compliance Statement
Note: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in
a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
y Reorient or relocate the receiving antenna.
y Increase the separation between the
equipment and receiver.
y Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
y Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications not
expressly approved by the party responsible for
compliance could void the user󾙓s authority to
operate the equipment.
Tested to comply with FCC standards FOR
HOME OR OFFICE USE
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.
CE Conformity
Products bearing the CE marking
comply with one or more of the
following EU Directives as may be
applicable:
RED 2014/53/EU; Low Voltage Directive
2014/35/EU; EMC Directive 2014/30/EU; RoHS
Directive 2011/65/EU. Compliance with these
directives is assessed using applicable European
Harmonized Standards. The point of contact for
regulatory matters is MSI,
MSI-NL Eindhoven 5706 5692 ER Son.
C-Tick Compliance
B󺭸 󺮟󺮟 (󺥯󼖄󼐘 󻦘󻼐󼼤󼁏󺮟󼓿󼔛)
󼓣 󺮟󺮟󻀃 󺥯󼖄󼐘(B󺭸) 󼕳󼓿󽁻󼕰󽋘󺮟󺮟󻗋󻺋
󼙫󻗋 󺥯󼖄󼌿󻺋 󻸛󼐘󽋇󻀃 󺧲󼒳 󻠘󼕰󼒫󻗋 󽋇󻟟,
󻠗󻉏 󼜯󼍜󼌿󻺋 󻸛󼐘󽋏 󻾇 󼓷󼀤󻀷󻁓.
B󳜶󲛂󳩏󸀐󸃔󶷉
󸃔󶷉󾗗󽘲󳜶󲛂󳩏󸀐󸃔󶷉
󾗘󸃔󶷉󾗗󲸜󳎎󵧨󲝐󱡋󵫞
󵸂󵵙󾗗󸃔󶷉
󱾭󱣭󴟆󸳽󳰛󱡋󵫞
󾗗󱾭󱣭󹤜󲸔󳑙󸤒󾗘󱾫󾊟󸒃
󴁩 󴇦 󳔿
󴦜󱾫󾊟󱘕
VCCI-B
Battery Information
European Union:
Batteries, battery packs, and
accumulators should not be
disposed of as unsorted household
waste. Please use the public
collection system to return, recycle,
or treat them in compliance with the
local regulations.
Taiwan:
󳏼󹧗󴭳󸒿󲒱󳻱
For better environmental protection,
waste batteries should be collected
separately for recycling or special
disposal.
California, USA:
The button cell battery may contain
perchlorate material and requires
special handling when recycled or
disposed of in California.
For further information please visit:
http://www.dtsc.ca.gov/hazardouswaste/
perchlorate/
CAUTION: There is a risk of explosion, if battery
is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Regulatory Notices

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI B450M GAMING PLUS and is the answer not in the manual?

MSI B450M GAMING PLUS Specifications

General IconGeneral
Audio chipRealtek ALC887
Cooling typePassive
Component forPC
Motherboard chipsetAMD B450
Audio output channels7.1 channels
Motherboard form factormicro ATX
Number of mounting holes6
Motherboard chipset familyAMD
Windows operating systems supportedWindows 10, Windows 7
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory32 GB
Supported memory clock speeds1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466 MHz
Processor socketSocket AM4
Compatible processor seriesAMD Athlon, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors1
Maximum graphics card memory2048 MB
Number of SATA II connectors0
Number of SATA III connectors4
HDMI version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controllerRealtek RTL8111H
Ethernet interface typeGigabit Ethernet
Cables includedSATA
BIOS typeUEFI
Weight and Dimensions IconWeight and Dimensions
Depth210 mm
Width244 mm
