CPU_FAN1, PUMP_FAN1, SYS_FAN1~2: Fan Connectors
Fan connectors can be classified as PWM (Pulse Width Modulation) Mode or DC Mode.
PWM Mode fan connectors provide constant 12V output and adjust fan speed with
speed control signal. DC Mode fan connectors control fan speed by changing voltage.
PWM Mode pin definition
Pin Signal Name Pin Signal Name
1 Ground 2 +12V
3 Sense 4 Speed Control Signal
Fan connector specifications
Connector Default fan mode Max. current Max. power
CPU_FAN1 PWM mode 2A 24W
PUMP_FAN1 PWM mode 3A 36W
SYS_FAN1~2 DC mode 1A 12W

Important
You can adjust fan speed in BIOS > HARDWARE MONITOR.
1
DC Mode pin definition
Pin Signal Name Pin Signal Name
1 Ground 2 Voltage Control
3 Sense 4 NC

MSI B660-A PRO DDR4 Specifications

General

Chipset	Intel B660
Memory Type	DDR4
Form Factor	ATX
Socket	LGA 1700
Memory Slots	4
Maximum Memory	128 GB
PCIe x1 Slots	2
M.2 Slots	2
SATA Ports	6
Audio	Realtek ALC897
RAID Support	RAID 0, 1, 5, 10
USB Ports	USB 3.2 Gen 2x2 (1), USB 3.2 Gen 2 (1), USB 3.2 Gen 1 (2), USB 2.0 (2)
