MSI B75MA-P45 series User Manual

En-17
Englsh
PCI Interrupt Request Routng
IRQ, or nterrupt request lnes, are hardware lnes over whch devces can send nterrupt
requests to the processor. The PCI IRQ pns are typcally connected to the PCI bus pns
as followed:
Order1 Order2 Order3 Order4
PCI Slot1 INT A# INT B# INT C# INT D#
Vdeo/ Graphcs Cards
If avalable, ths manboard takes advantage of the CPU’s ntegrate graphcs processor,
but dscrete vdeo cards can be nstalled by way of the manboard’s expanson slots.
Addng on one or more dscrete vdeo cards wll sgn󰘰cantly boost the system’s graphcs
performance. For best compatblty, MSI graphcs cards are recommended.
Sngle Vdeo Card Installaton
Determne what type of expanson slot(s) the vdeo card wll use. Locate the expan-
son slot(s) on the manboard. Remove any protectve expanson slot covers from
the computer case.
Lne up the vdeo card on top of the expanson slot(s) wth the dsplay ports facng
out of the computer case. For a sngle vdeo card nstallaton, usng the PCI_E2 slot
s recommended.
Push the vdeo card nto ts expanson slot(s). Dependng on the expanson slot(s)
used, there should be clp(s) on the expanson slot(s) that wll lock n place.
If needed, screw the edge of the graphcs card to the computer case. Some vdeo
cards mght requre a power cable drectly from the power supply.
Please consult your vdeo card’s manual for further nstructons regardng drver
nstallaton or other specal settngs.
1.
2.
3.
4.
5.

MSI B75MA-P45 series Specifications

General

Form Factor	Micro ATX
Chipset	Intel B75
Socket	LGA 1155
Max Memory	32GB
Memory Standard	DDR3 1600/1333/1066 MHz
PCI Express x16	1
SATA 6Gb/s	1
SATA 3Gb/s	5
Audio	Realtek ALC887
RAID Support	No
USB 3.0	2 x USB 3.0
USB 2.0	8 x USB 2.0
LAN	Realtek 8111E
PCI Express x1	2
