MSI B75MA-P45 series User Manual

En-23
Englsh
JAUD1: Front Panel Audo Connector
Ths connector allows you to connect the front audo panel located on your computer
case. Ths connector s complant wth the Intel
®
Front Panel I/O Connectvty Desgn
Gude.
1.MI
C L
3.MI
C R
10.Head
P
hone
Detection
5.Head
P
hone
R
7.SENSE_SEN
D
9.Head P
hone
L
8.No
Pi
n
6.MI
C D
etection
4.NC
2
.Ground
JTPM1: TPM Module Connector
Ths connector connects to a TPM (Trusted Platform Module). Please refer to the TPM
securty platform manual for more detals and usages.
* The MB layout n ths 󰘰gure s for reference only.
1
15V
10.N o
P
in
14.G ro un d
8.5V
P
ower
12.G ro un d
6.Se ri al
I
RQ
4.3. 3V
P
ower
2.3V
S
t
andb y
p
ower
1.LP
C
C
loc
k
3.LP
C
R
eset
5.LP
C
a
ddre s
s
&
d
at
a
p
in0
7.LP
C
a
ddre s
s
&
d
at
a
p
in1
9.LP
C
a
ddre s
s
&
d
at
a
p
in2
11
.LPC
a
ddre s
s
&
d
at
a
p
in3
13.L P
C
F
rame
TPM module s optonal

MSI B75MA-P45 series Specifications

General

Form Factor	Micro ATX
Chipset	Intel B75
Socket	LGA 1155
Max Memory	32GB
Memory Standard	DDR3 1600/1333/1066 MHz
PCI Express x16	1
SATA 6Gb/s	1
SATA 3Gb/s	5
Audio	Realtek ALC887
RAID Support	No
USB 3.0	2 x USB 3.0
USB 2.0	8 x USB 2.0
LAN	Realtek 8111E
PCI Express x1	2
