MSI B75MA-P45 series User Manual

En-26
MS-7798 Manboard
JBAT1: Clear CMOS Jumper
There s CMOS RAM onboard that s external powered from a battery located on the
manboard to save system con󰘰guraton data. Wth the CMOS RAM, the system can
automatcally boot nto the operatng system (OS) every tme t s turned on. If you want
to clear the system con󰘰guraton, set the jumpers to clear the CMOS RAM.
Keep Data Clear Data
1 1
Important
You can clear the CMOS RAM by shortng ths jumper whle the system s o󰘯. Afterwards,
open the jumper . Do not clear the CMOS RAM whle the system s on because t wll
damage the manboard.

MSI B75MA-P45 series Specifications

General

Form Factor	Micro ATX
Chipset	Intel B75
Socket	LGA 1155
Max Memory	32GB
Memory Standard	DDR3 1600/1333/1066 MHz
PCI Express x16	1
SATA 6Gb/s	1
SATA 3Gb/s	5
Audio	Realtek ALC887
RAID Support	No
USB 3.0	2 x USB 3.0
USB 2.0	8 x USB 2.0
LAN	Realtek 8111E
PCI Express x1	2
