MSI B75MA-P45 series User Manual

En-29
Englsh
Operaton
Clck BIOS II allows you to control BIOS settngs wth the mouse and the keyboard. The
followng table lsts and descrbes the hot keys and the mouse operatons.
Hot key Mouse Descrpton
<↑↓→← >
Move the cursor
Select Item
<Enter>
Clck/ Double-
clck the left
button
Select Icon/ Feld
<Esc>
Clck the rght
button
Jump to the Ext menu or return to the prevous from
a submenu
<+> Increase the numerc value or make changes
<-> Decrease the numerc value or make changes
<F1> General Help
<F4> CPU Spec󰘰catons
<F5> Enter Memory-Z
<F6> Load optmzed defaults
<F10> Save Change and Reset
<F12> Save a screenshot to a FAT/FAT32 USB drve
Sub-Menu
An arrow symbol appears to the left of certan 󰘰elds that means t contans a sub-menu.
A sub-menu contans addtonal optons for a 󰘰eld parameter. You can use arrow keys
( ↑↓ ) or mouse to hghlght the 󰘰eld and press <Enter> or mouse double left clck to
enter the sub-menu. If you want to return to the prevous menu, just press the <Esc >
or clck the rght mouse button.
General Help
Clck BIOS II provdes General Help wndow. You can call up the wndow from any BIOS
menu by smply pressng <F1> or clck HELP on BIOS settng screen. The Help wndow
lsts the approprate keys to use and the possble selectons for the hghlghted tem.

MSI B75MA-P45 series Specifications

General

Form Factor	Micro ATX
Chipset	Intel B75
Socket	LGA 1155
Max Memory	32GB
Memory Standard	DDR3 1600/1333/1066 MHz
PCI Express x16	1
SATA 6Gb/s	1
SATA 3Gb/s	5
Audio	Realtek ALC887
RAID Support	No
USB 3.0	2 x USB 3.0
USB 2.0	8 x USB 2.0
LAN	Realtek 8111E
PCI Express x1	2
