En-32
MS-7798 Manboard
Adjusted DRAM Frequency
It shows the adjusted DRAM frequency. Read-only.
DRAM Tmng Mode
Select whether DRAM tmng s controlled by the SPD (Seral Presence Detect) EEP
-
ROM on the DRAM module. Settng to [Auto] enables DRAM tmngs and the followng
“Advanced DRAM Conguraton” sub-menu to be determned by BIOS based on the
conguratons on the SPD. Selectng [Lnk] or [Unlnk] allows users to congure the
DRAM tmngs for each channel and the followng related “Advanced DRAM Congura
-
ton” sub-menu manually.
Advanced DRAM Conguraton
Press <Enter> to enter the sub-menu.
Command Rate
Ths settng controls the DRAM command rate.
tCL
Controls CAS latency whch determnes the tmng delay (n clock cycles) of startng
a read command after recevng data.
tRCD
Determnes the tmng of the transton from RAS (row address strobe) to CAS (col
-
umn address strobe). The less clock cycles, the faster the DRAM performance.
tRP
Controls number of cycles for RAS (row address strobe) to be allowed to pre-charge.
If nsucent tme s allowed for RAS to accumulate before DRAM refresh, the DRAM
may fal to retan data. Ths tem apples only when synchronous DRAM s nstalled
n the system.
tRAS
Determnes the tme RAS (row address strobe) takes to read from and wrte to mem
-
ory cell.
tRFC
Ths settng determnes the tme RFC takes to read from and wrte to a memory
cell.
tWR
Determnes mnmum tme nterval between end of wrte data burst and the start of a
pre-charge command. Allows sense amplers to restore data to cell.
tWTR
Determnes mnmum tme nterval between the end of wrte data burst and the start
of a column-read command; allows I/O gatng to overdrve sense amples before
read command starts.
tRRD
Speces the actve-to-actve delay of derent banks.
tRTP
Tme nterval between a read and a precharge command.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
