MSI B75MA-P45 series User Manual

En-35
Englsh
Power Technology
Ths tem allows you to select the Intel Dynamc Power technology mode.
C1E Support
Enable system to reduce CPU power consumpton whle dle. Not all processors
support Enhanced Halt state (C1E).
OverSpeed Protecton
Montors current CPU draw as well as power consumpton; f t exceeds a certan
level, the processor automatcally reduces ts clock speed. For overclockng, t s
recommended ths feature s dsabled.
Intel C-State
C-state s a power management state that detects when the system s dle and
lowers power consumpton accordngly.
Package C State lmt
Ths 󰘰eld allows you to select a C-state mode.
Long duraton power lmt (W)
Ths 󰘰eld allows you to adjust the TDP power lmt for the long duraton.
Long duraton mantaned (s)
Ths 󰘰eld allows you to adjust the mantanng tme for long duraton power lmt.
Short duraton power lmt (W)
Ths 󰘰eld allows you to adjust the TDP power lmt for the short duraton.
Prmary/ Secondary Plane Current value (A)
These 󰘰elds allow you to adjust over current value of CPU (prmary plane)/ GPU
(secondary plane) for turbo rato.
Prmary/ Secondary plane turbo power lmt (W)
These 󰘰elds allow you to adjust the turbo power lmt of CPU (prmary plane)/ GPU
(secondary plane) for turbo boost.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶

MSI B75MA-P45 series Specifications

General

Form Factor	Micro ATX
Chipset	Intel B75
Socket	LGA 1155
Max Memory	32GB
Memory Standard	DDR3 1600/1333/1066 MHz
PCI Express x16	1
SATA 6Gb/s	1
SATA 3Gb/s	5
Audio	Realtek ALC887
RAID Support	No
USB 3.0	2 x USB 3.0
USB 2.0	8 x USB 2.0
LAN	Realtek 8111E
PCI Express x1	2
