Motherboard Speci󰘰cations
CPU
Support
4th Generation Intel
®
Core™ i7 / Core™ i5 / Core™ i3 / Pentium
®
/
Celeron
®
processors for LGA 1150 socket
■
Chipset Intel
®
B85 Express Chipset■
Memory
Support
4x DDR3 memory slots supporting up to 32GB
Supports DDR3 1600/ 1333/ 1066 MHz
Dual channel memory architecture
Supports non-ECC, un-bu󰘯ered memory
Supports Intel
®
Extreme Memory Pro󰘰le (XMP)
■
■
■
■
■
Expansion
Slots
1x PCIe 3.0 x16 slot
2x PCIe 2.0 x1 slots
1x PCI slot
■
■
■
Onboard
Graphics
1x HDMI port, supporting the maximum resolution of
4096x2160@24Hz, 24bpp/ 2560x1600@60Hz, 24bpp/
1920x1080@60Hz, 36bpp
1x VGA port, supporting a maximum resolution of 1920x1200 @
60Hz
1x DVI-D port, supporting a maximum resolution of 1920x1200 @
60Hz
■
■
■
Storage Intel
®
B85 Express Chipset
4x SATA 6Gb/s ports (SATA1~4)
2x SATA 3Gb/s ports (SATA5~6)
Supports Intel
®
Rapid Start Technology, Intel
®
Smart Connect
Technology*
* Supports Intel Core processors on Windows 7 and Windows 8.
■
-
-
-
USB Intel B85 Express Chipset
4x USB 3.0 ports (2 ports on the back panel, 2 ports available
through the internal USB 3.0 connector)
8x USB 2.0 ports (4 ports on the back panel, 4 ports available
through the internal USB connectors)
■
-
-
Audio Realtek
®
ALC887 Codec
7.1-Channel High De󰘰nition Audio
■
-
LAN 1x Realtek
®
8111G Gigabit LAN controller■
Back Panel
Connectors
1x PS/2 keyboard port
1x PS/2 mouse port
4x USB 2.0 ports
1x HDMI port
2x USB 3.0 ports
1x VGA port
1x DVI-D port
1x LAN (RJ45) port
3x audio jacks
■
■
■
■
■
■
■
■
■

MSI B85M-E45 Specifications

General

Form Factor	Micro ATX
Chipset	Intel B85
Socket	LGA 1150
Memory Slots	4
Max Memory	32 GB
Memory Speed	DDR3 1600/1333/1066 MHz
PCI Express x16	1
PCI Express x1	2
SATA Ports	4 x SATA 6Gb/s, 2 x SATA 3Gb/s
USB Ports	4 x USB 3.0, 8 x USB 2.0
Video Outputs	1 x DVI-D, 1 x VGA
Audio	Realtek ALC887, 7.1-Channel
LAN	Realtek RTL8111G Gigabit LAN
