Thank you for choosing the B85M-P33 V3 Series (MS-7817 v8.X) Micro-ATX
motherboard. The B85M-P33 V3 Series motherboards are based on Intel B85 chipset
󰘲󰘰
the B85M-P33 V3 Series motherboards deliver a high performance and professional
desktop platform solution.
Layout
BAT1
JAUD1
JCOM1
JTPM1
JFP1
JUSB2
JUSB1
SATA4SATA
6S
ATA3SATA5
JFP2
PCI_E1
SYSFAN1
JPWR2
PCI_E2
PCI_E3
JCI1
JBAT1
SATA1_2
JUSB3
JPWR1
CPUFAN1
DIMM1
DIMM2
Top : mouse
Bottom: keyboard
Top: LAN jack
Bottom: USB2.0 ports
T:Line-In
M:Line- Out
B:MIC-Int
USB3.0 orts
VGA port
DVI port
