2-16

Introductions

Left Side View

1. Power Connector

To connect the AC/DC adapter and supply power for the notebook.

2. RJ-45 Connector

The Ethernet connector is used to connect a LAN cable for network connection.

3. VGA Port

The 15-pin D-Sub VGA port allows you to connect an external monitor or other standard

VGA-compatible device (such as a projector) for a great view of the computer display.

4. Ventilator

The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.

1. Power Connector

2. RJ-45 Connector

3. VGA Port

4. Ventilator

5. HDMI Connector

6. USB Port
