CX70/CR70 (MS-1755) Disassembly Guide
2BOTTOM DOOR ASSY
2.1 Remove the 5 screws (M2.5*5.5mm). Then
remove the Bottom door.
Attention: the screw driver touque is: 2.0-2.5 gf-cm
Component P/N Qty
Bottom door E2P-751J211-P89 1
Screw E43-1255501-H29 6
