Right Side View
1. Audio Port Connectors
Make high quality sound blaster with stereo system and Hi-Fi function supported. Connect your
speakers to the proper connectors as shown below.
Mic In: Used for an external microphone.
Connect the Center and Subwoofer speakers here.
Line In: Used for an external audio device.
Connect the Rear speakers here.
Line Out/ SPDIF-out : Used for speakers or
headphones. The S/PDIF connector is also provided
for digital audio transmission to external speakers
through an optical fiber cable.
1. Audio Port Connectors
2. USB Port
3. Card Reader
4. ExpressCard Slot
1
2
3
4
