MSI G4101-01 - System Specifications

7
System Specifications
System Specifications
Model G4101-01
Form Factor
4U
Dimensions
17.2”W (447.9mm) x 6.9”H (176mm) x 32.6”D (827.3mm)
Processor
∙ 1 x AMD® EPYC™ 9004 Series Processors
- Processor socket SP5 (LGA 6096)
- Cores up to 128C
- TDP 500W
Memory
∙ 12 x DDR5 DIMM slots
- Supports 12-Channel DDR5
- Supports RDIMM/ 3DS RDIMM, up to 128GB, 4800MT/s (1DPC), ECC
Internal Storage
2 x M.2 M-Key (PCIe 3.0 x4/x2, 2280/ 22110)
Drive Bays
∙ 12 x 2.5” Hybrid hot-swap drive bays
- Supports U.2 NVMe 4.0/ SAS/ SATA signals
Expansion Slots
∙ 6 x PCIe 5.0/4.0 x16 Full-height/Full-length (FH/FL) slots
- 4 x PCIe 5.0 x16 slots for triple slot GPGPU
- 2 x PCIe 4.0 x16 slots (PCIe 4.0 x8/x16 signal from CPU)
Security
∙ TPM 2.0
∙ Case intrusion switch
Server
Management
∙ Aspeed AST2600 IPMI 2.0 with iKVM support
∙ 1 x GbE RJ45 port (Mgmt.)
- Realtek® RTL8211FD-CG
Cooling
∙ 1 x Passive CPU heatsink @280W (Optional)
∙ 1 x CPU liquid cooling @500W
Environment
∙ Operating Temperature: 0°C ~ 35°C
∙ Non-operating Temperature: -20°C ~ 70°C
∙ Non-operating Relative Humidity: 5% ~ 85% (non-condensing)
Accessory
1 x Slide Rail (Optional)
Certifications
CE, FCC (Class A)
