4-15
BIOS Setup
Creating RAID Volume
To create RAID Volume, follow the steps below:
1. Reboot during POST, the following
message will appear then press
<CTRL-I> to enter Configuration Utility.
2. Enter Main Screen of Intel Rapid
Storage Technology. Select “Create
RAID Volume”, and press ENTER.
It takes BOTH hard disks in
the notebook to make
successful RAID0 volume
creation.
1
2
Intel(R) Rapid Storage Technology - Option ROM - 9.5.0.1037
Copyright(C) 2003-06 Intel Corporation, All Rights Reserved.
Physical Devices:
Port Device Model Serial # Size Type/Status(Vol ID)
4 WDC WD5000 BEVT-2 WD-WXBA8929596 465.7GB
5 WDC WD5000BEVT-2 WD-WXB0A8979170 46 5.7
Press to enter Configuration Utility...
0 Volume0 RAID0(Stripe) 128KB 931.5GB Yes
<CTRL-I>
