GX70（MS-176K）Disassembly Guide
■ 5、THERMAL-KIT、CPU AND DRAM
5.4：Push the two side shielding of DRAM as pic
shows; Then remove the DRAM Module according
the direction as pic shows.
Component
P/N
Qty
DRAM Module
S7C-S48A501-A97
2
5.5：Remove 1 screw (M2.5*5mm); then remove
the VGA card as pic shows.
Attention: the screw driver torque is: 1.8-2.2Kgf-cm
Component
P/N
Qty
VGA Card
607-1W0D1-01S
1
Screw
E43-1255002-G68
1
5.6：Remove 2 screws(M2*4m); then remove the
HDD2 Board.
Attention: the screw driver torque is: 1.2-1.6Kgf-cm
Component
P/N
Qty
HDD2 Board
607-176KD-01S
1
Screw
E43-1204002-G68
2
