MSI H310M PRO-M2 PLUS Quick Start Guide

10
󽐳󻟣 I/O 󽂗󺹿
SATA1~4: SATA 6Gb/s 󼱓󺺔󼺟
󼓣 󼱓󺺔󼺟󻀃 SATA 6Gb/s 󼓧󼺟󽄇󼓣󼀓 󽅛󽀧󼓴󻀷󻁓. 󺥰 󼱓󺺔󼺟󼌿 󽋇󺸇󼓇 SATA 󼔔󼯇󻛫 󼍟󺨟󽋏
󻾇 󼓷󼀤󻀷󻁓.
SATA1
SATA2
SATA3
SATA4
󼚀󼐃󻸛󽋜
y M.2 SATA SSD󺥯 M2_1 󼀛󻗞󼌿 󻺓󼯇󻆋 󺨬󼐟 SATA1 󽅛󽀧󻛫 󻸛󼐘󽋏 󻾇 󼌵󼀤󻀷󻁓.
y SATA 󼱯󼓣󻮃󼒳 90󻄳󻗋 󺰬󼜯 󻜷󻺧󼐃. 󺭧󻕣 󺨬󼐟, 󼕳󻼐 󼚀 󻃟󼓣󼺟󺥯 󻻿󻸰󻆏 󻾇 󼓷󼀤󻀷󻁓.
y SATA 󼱯󼓣󻮃󼓇 󼌀󼠬 󻠗󻆿󼌿 󻅈󼓫󽋋 󽉻󻕛󺭧󺥯 󼓷󼜯󻜻 󺩤󺥳 󼕷󼋬󼒳 󼑳󽋣 󽉻󻔚 󼱓󺺔󼺟󻛫
󻟃󼓧󻩣󻉋󼌿 󼍟󺨟󽋏 󺧲󼒳 󺫻󼔔󽋘󻀷󻁓.
JFP1, JFP2: 󼕳󻟣 󽂗󺹿 󼱓󺺔󼺟
󼓣 󼱓󺺔󼺟󻛫 󻸛󼐘󽋇󼍛 󼕳󻟣 󽂗󺹿󼌿 󼓷󻀃 󼀓󼑳󼯇 󻥾 LED󻛫 󼍟󺨟󽋏 󻾇 󼓷󼀤󻀷󻁓.
JFP1
Reserved
++
+
+
--
-
-
Power LED
HDD LED
Reset Switch
Power Switch
1
2
10
9
1 HDD LED + 2 Power LED +
3 HDD LED - 4 Power LED -
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
+
+
-
-
Speaker
Buzzer
1
JFP2
1 Speaker - 2 Buzzer +
3 Buzzer - 4 Speaker +
Downloaded from ManualsNet.com search engine

MSI H310M PRO-M2 PLUS Specifications

General

Form Factor	Micro-ATX
Chipset	Intel H310
CPU Socket	LGA 1151
Memory Slots	2 x DIMM
Maximum Memory	32 GB
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
Storage Interface	4 x SATA 6Gb/s
USB Ports	4 x USB 3.1 Gen1, 6 x USB 2.0
Audio	Realtek ALC887
LAN	Realtek 8111H Gigabit LAN
Video Outputs	1 x HDMI, 1 x VGA
RAID Support	No
Memory Speed	2666/2400/2133 MHz
