Hardware Setup ▍
MS-7638
Hardware Setup ▍
MS-7638
back paneL
Mouse/Keyboard
The standard PS/2
®
mouse/keyboard DIN connector s for a PS/2
®
mouse/keyboard.
USB Port
The USB (Unversal Seral Bus) port s for attachng USB devces such as keyboard,
mouse, or other USB-compatble devces.
LAN
The standard RJ-45 LAN jack s for connecton to
the Local Area Network (LAN). You can connect a
network cable to t.
LED Color LED State Condton
Left Yellow O󰘯 LAN lnk s not establshed.
On(Steady state) LAN lnk s establshed.
On(brghter & pulsng) The computer s communcatng wth another computer on the LAN.
Rght
Green O󰘯 10 Mbts/sec data rate s selected.
On 100 Mbts/sec data rate s selected.
Orange On 1000 Mbts/sec data rate s selected.
VGA Port
The DB15-pn female connector s provded for montor.
HDMI Port
The Hgh-De󰘰nton Multmeda Interface (HDMI) s an all-dgtal audo/vdeo nterface
capable of transmttng uncompressed streams. HDMI supports all TV format, ncludng
standard, enhanced, or hgh-de󰘰nton vdeo, plus mult-channel dgtal audo on a sngle
cable.
▶
▶
▶
▶
▶
Mouse/
Keyboard
USB Port
LAN
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-Out
HDMI Port
USB Port
Yellow Green/ Orange
VGA Port
