LONG DRIVE (UNDER/OVER DRIVE) GEAR REDUCER
(4.61:1 REDUCTION RATIO)
LEFT HAND 5
LEFT HAND 9
LEFT HAND 4
LEFT HAND 13 LEFT HAND 14
*POSITION DIMENSIONS ROUNDED TO THE NEAREST 1/16"
6 5/16"
15 1/4"
16 1/2"
16 1/2"
16 1/2"
6 5/16"
15 1/4"
