MSI Hybrid Triplex - Page 27

6 5/16"
15 1/4"
16 1/2"
16 1/2"
16 1/2"
6 5/16"
15 1/4"
LONG DRIVE (UNDER/OVER DRIVE) GEAR REDUCER
(4.61:1 REDUCTION RATIO)
RIGHT HAND 14
RIGHT HAND 4 RIGHT HAND 5
RIGHT HAND 9 RIGHT HAND 13
*POSITION DIMENSIONS ROUNDED TO THE NEAREST 1/16"
C
A
12345678
G
F
E
D
B
Revision K 03/12/2019
MSI - A Division of Dixie Iron Works, Ltd. All rights reserved.
Page 24
