MSI Hybrid Triplex - Page 49

ITEM NO. DESCRIPTION
PART NUMBER
3.25" 3.50" 4.00" 4.50"
1 BACK-UP RING, SB FE SIDE OC0066
2 BACK-UP RING, SB PE SIDE OC0139 OC0068 OC0070 OC0072
3 DISCHARGE COVER NUT FEC0005
4 FLUID END ADAPTER FEC0403
5 FLUID END PLUNGER FEC0315 FEC0316 FEC0317 FEC0318
6 GAUGE CONNECTION FEC0011
7 GAUGE CONNECTION RETAINER NUT FEC0012
8 LANTERN RING FEC0358 FEC0355 FEC0356 FEC0357
9 O-RING, PACKING NUT OC0150
10 O-RING, SB FE SIDE OC0065
11 O-RING, SB PE SIDE OC0138 OC0067 OC0069 OC0071
12 PACKING NUT FEC0351 FEC0348 FEC0349 FEC0350
13 PACKING SET FEC0258 FEC0054 FEC0055 FEC0040
14 SEAL, SUCTION COVER FEC0013
15 SEAL, DISCHARGE COVER FEC0015
16 STUFFING BOX ADAPTER FEC0260 FEC0058 FEC0059 FEC0036
17 SUCTION COVER GLAND FEC0340
18 SUCTION COVER NUT FEC0341
19 SUCTION COVER NUT BOLT HC0454
20 VALVE FEC0472 (INSERT FEC0472-I)
21 VALVE SEAT FEC0473
22 VALVE SPRING FEC0003
23 VALVE STOP ASSEMBLY FEC0383
D
C
A
12345678
G
F
E
B
F
L
U
ID
E
N
D
A
S
S
E
M
B
L
Y
-
S
E
C
T
IO
N
,
3
.
2
5
"
-
4
.
5
0
"
14
3
4
6
7
23
15
17
18
19
20
20
21
21
22
22
5
A
16
HC0507
DOWEL PIN
1
2
8
11
10
9
12
13
RETENTION SCREW
HC0946
DETAIL A
Revision K 03/12/2019
MSI - A Division of Dixie Iron Works, Ltd. All rights reserved.
Page 46
