Replacing the CPU
While replacing the CPU, always turn off the ATX power supply or unplug the power supply’s power
cord from grounded outlet first to ensure the safety of CPU.
Memory
The mainboard provides 2 slots for 184-pin DDR SDRAM DIMM (Double In-Line Memory Module)
modules and supports the memory size up to 2GB. You can install PC3200/DDR400, PC2700/DDR333,
or PC2100/DDR266 unbuffered DIMM modules on the DDR DIMM slots (DDR 1~2). Plugging
memories in DIMM1 and DIMM2 makes the system reach the optimum system performance.
For the updated supporting memory modules, please visit
http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_trp_list.php.
Memory Population Rules
Install at least one DIMM module on the slots. Each DIMM slot supports up to a maximum size of 1GB.
Users can install either single- or double-sided modules to meet their own needs. Please note that each
DIMM can work respectively for single-channel DDR, but there are some rules while using DDR.
Memory modules can be installed in any combination as follows:
Slot Memory Module
64MB~2GB
DIMM1 DIMM2 Max Speed
Single x DDR 400
x Single DDR 400
Single Single DDR 400
Single Double DDR 400
Double Single DDR 400
Double Double DDR 333
MSI Reminds You...
The maximum memory speed decreases when both DIMM1 and DIMM2 slots are installed with
double-sided memory module.
Please refer to http://www.msi.com.tw/program/products/mainboard/mbd/pro_mbd_trp_list.php for
compatible DDR modules.
