Using 4- or 6-Channel Audio Function
Connecting the Speakers
When you have set the Multi-Channel Audio Function mode properly
in the software utility, connect your speakers to the correct phonejacks
in accordance with the setting in software utility.
2-Channel Mode for Stereo-Speaker Output
Refer to the following diagram and caption for the function of each
phonejack on the back panel when 2-Channel Mode is selected.
5
6
4
Back Panel
3
1
2
2 MIC
3 Line In
1 Line Out (Front channels)
