MSI MAG B550 TOMAHAWK - Jaud1: 전면 오디오 커넥터; Jfp1, Jfp2: 전면 패널 커넥터

19
󺭞󻼣󽉺󺨎󼒆
󼗶󻡦󼐖󻌆󼐖󼳖󺼗󼼢
󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󼗶󻡦󽄚󺼂󼕊󼐖󻌆󼐖󼖟󼔶󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖
1
2 10
9
1 MIC L 2 Ground
3 MIC R 4 NC
5 Head Phone R 6 MIC Detection
7 SENSE_SEND 8 No Pin
9 Head Phone L 10 Head Phone Detection
󼗶󻡦󽄚󺼂󼳖󺼗󼼢
󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󼗶󻡦󽄚󺼂󼏂󼕺󻂆󼂖󼓶󼱊󻨁󻝮󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖
1
JFP2
+
+


Speaker
Buzzer
1  2 Buzzer +
3  4 Speaker +
1
2 10
9
+
+
+  
+
󼗶󼓂
HDD LED 󻞞󻼽󼂖󼓶󼱊
Reserved
󼗶󼓂󼂖󼓶󼱊
JFP1
1 HDD LED + 2 Power LED +
3  4 
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
