MSI MAG B550 TOMAHAWK - JTPM1: TPM Anschluss; JUSB1~2: USB 2.0 Anschlüsse

22
Übersicht der Komponenten


verbinden.
1
2 10
9
1 VCC 2 VCC
3  4 
5 USB0+ 6 USB1+
7 Ground 8 Ground
9 No Pin 10 NC

Wichtig
 

Schäden kommen.
 
Sie bitte die MSI® DRAGON CENTER Software.
1
2
12
11
1 SPI Power 2 SPI Chip Select
3
Master In Slave Out (SPI Data) 4 Master In Slave In (SPI Data)
5 Reserved 6 SPI Clock
7 Ground 8 SPI Reset
9 Reserved 10 No Pin
11 Reserved 12 Interrupt Request



bitte dem TPM Plattform Handbuch.
