Overview
1-51-4
h Rear View
1
2
1
4 5
6
8
3
10
15 16
9
11
13
12
14
7
1
Ventilator
The ventilator on the enclosure is used for air convection and to prevent the
equipment from overheating� Do not cover the ventilator�
2
Power Jack
Power supplied through this jack supplies power to your system�
3
Line-In
Used for connecting external audio outputting devices�
SS-Out
Side surround sound line out in 7�1 channel mode�
4
Line-Out
This connector is provided for headphones or speakers�
5
Mic-In
This connector is provided for microphones�
