MSI MEG Aegis Series User Manual

Overview
1-51-4
6
CS-Out
Center/ Subwoofer Out in 5�1/ 7�1 channel mode�
7
RS-Out
Rear-Surround Out in 4/ 5�1/ 7�1 channel mode�
8
S/PDIF-Out
This S/PDIF (Sony & Philips Digital Interconnect Format) connector is
provided for digital audio transmission to external speakers through an
optical 󰘰ber cable.
9
RJ-45 LAN Jack (2.5G)
The standard RJ-45 LAN jack is provided for connection to the Local Area
Network (LAN)� You can connect a network cable to it�
Green/ OrangeYellow
LED Color LED State Condition
Left Yellow O󰘯 LAN link is not established�
On (steady state) LAN link is established�
On (blinking) The computer is communicating with another computer
on the LAN�
Right Green O󰘯 10 Mbit/sec data rate is selected�
On 100 Mbit/sec data rate is selected�
On 1000 Mbit/sec data rate is selected�
Orange On 2500 Mbit/sec data rate is selected�
10
RJ-45 LAN Jack (1G)
The standard RJ-45 LAN jack is provided for connection to the Local Area
Network (LAN)� You can connect a network cable to it�
Green/ OrangeYellow
LED Color LED State Condition
Left Yellow O󰘯 LAN link is not established�
On (steady state) LAN link is established�
On (blinking) The computer is communicating with another computer
on the LAN�
Right Green O󰘯 10 Mbit/sec data rate is selected�
On 100 Mbit/sec data rate is selected�
Orange On 1000 Mbit/sec data rate is selected�

MSI MEG Aegis Series Specifications

General

Series	MEG Aegis
Category	Desktop
Graphics	NVIDIA GeForce RTX 3080
Operating System	Windows 11 Home / Windows 11 Pro (depending on the specific model)
Power Supply	750W 80 Plus Gold
Connectivity	Wi-Fi 6
Ports	USB 3.2 Gen 2
