Overview of Components
Bandwidth share table
PCI_E4, M2_3, M2_4 & SATA5~8
Slot Bandwidth configuration
PCI_E4 (Chipset) x8 x4
M2_3 (Chipset) PCIe SATA
M2_4 (Chipset) PCIe SATA PCIe SATA
SATA5~6 (Chipset) V V
SATA7~8 (Chipset)
AMD Ryzen™ 2000 G-Series and 3000 G-Series desktop processors
Slot Single VGA 2-Way VGA
PCI_E1 (CPU) @ x8 @ x8
PCI_E2 (CPU) — —
PCI_E3 (Chipset) x1 x1
PCI_E4 (Chipset) x8/ x4 @x8/ @x4*
⚠
Important
PCI_E4, M2_3, M2_4 and SATA5~8 share the same bandwidth. Please refer to the
following Bandwidth share table for more details.
