Overview of Components
JOC_RT1: OC Retry Button
This connector allows you to connect a button. When you press and hold the button,
the system will keep retrying OC items until it boot up successfully.
Normal
(default)
Normal
(default)
Force into BIOS
Retry OC
JOC_FS1
JOC_RT1
JOC_FS1: OC Force Enter BIOS Button
This connector allows you to connect a button. When you press the button, the system
will be forced into BIOS without showing the OC_FAIL message.
