MSI MEG Z490 UNIFY User Manual

92 pages

To Next Page

To Previous Page

Specifications

Continued from previous page

RAID

Intel® Z490 Chipset

∙ Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA

storage devices

∙ Supports RAID 0, RAID 1 and RAID 5 for M.2 PCIe storage

devices

LAN ∙ 1x Realtek® 8125B 2.5G LAN controller

Wireless/ Bluetooth

Intel® AX201

∙ MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps

∙ 802.11ac; WiFi 6 pre certified

∙ Bluetooth 5.0, FIPS, FISMA

∙ 1x M.2 Socket with E key (Wi-Fi mode)

USB

∙ Intel® Z490 Chipset

▪ 4x USB 3.2 Gen 2 10Gbps ports (3 Type-A ports on the

back panel, 1 Type-C internal connector)

▪ 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the

back panel, 2 ports through the internal USB connector)

▪ 6x USB 2.0 ports (2 Type-A ports on the back panel, 4

ports through the internal USB 2.0 connectors)

∙ ASMedia® 3241 chipset

▪ 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back

panel

Audio

Realtek® ALC1220 Codec + ESS E9018Q2C combo DAC

∙ 7.1-Channel High Definition Audio

∙ Supports S/PDIF output

Back Panel

Connectors

∙ 1x Clear CMOS

∙ 1x Flash BIOS button

∙ 1x PS/2 keyboard/ mouse combo port

∙ 2x USB 2.0 ports

∙ 2x USB 3.2 Gen 1 5Gbps Type-A ports

∙ 3x USB 3.2 Gen 2 10Gbps Type-A ports

∙ 1x USB 3.2 Gen 2x2 20Gbps Type-C port

∙ 1x LAN (RJ45) port

∙ 1x Wi-Fi antenna connector

∙ 1x Optical S/PDIF OUT connector

∙ 5x OFC audio jacks

Continued on next page
