MSI MEG Z490 UNIFY User Manual

92 pages

To Next Page

To Previous Page

Specifications

Continued from previous page

Internal Connectors

∙ 1x 24-pin ATX main power connector

∙ 2x 8-pin ATX 12V power connectors

∙ 6x SATA 6Gb/s connectors

∙ 3x M.2 slots (M-Key)

∙ 1x USB 3.2 Gen 2 10Gbps Type-C port

∙ 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2

USB 3.2 Gen 1 5Gbps ports)

∙ 2x USB 2.0 connectors (supports additional 4 USB 2.0

ports)

∙ 1x 4-pin CPU fan connector

∙ 1x 4-pin water-pump connector

∙ 6x 4-pin system fan connectors

∙ 1x front panel audio connector

∙ 2x system panel connectors

∙ 1x Chassis Intrusion connector

∙ 1x slow mode jumper

∙ 1x power button

∙ 1x reset button

∙ 1x 4-pin RGB LED connector

∙ 2x 3-pin RAINBOW LED connectors

∙ 1x 3-pin CORSAIR LED connector

LED Features

∙ 1x LED Control switch

∙ 4x EZ Debug LED

∙ 1x 2-Digit Debug Code LED

I/O Controller NUVOTON NCT6687 Controller Chip

Hardware Monitor

∙ CPU/System temperature detection

∙ CPU/System fan speed detection

∙ CPU/System fan speed control

Form Factor

∙ ATX Form Factor

∙ 12 in. x 9.6 in. (30.5 cm x 24.4 cm)

BIOS Features

∙ 1x 256 Mb flash

∙ UEFI AMI BIOS

∙ ACPI 6.2, SM BIOS 3.2

∙ Multi-language

Continued on next page
