MSI MEG Z690 ACE User Manual

18
Specifications
Continued from previous column
RAID
∙ Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices*
∙ Supports RAID 0, RAID 1 , RAID 5 and RAID 10 for M.2
NVMe storage devices
* SATAA & SATAB do not support RAID function.
USB
∙ Intel® Z690 Chipset
▪ 2x USB3.2 Gen2x2 20Gbps ports (2 Type-C internal
connectors)
▪ 4x USB 3.2 Gen 2 10Gbps ports (1 Type-C port on the
back panel, 3 Type-A ports on the back panel)
∙ Hub-GL3590
▪ 4x USB 3.2 Gen 2 10Gbps Type-A ports on the back
panel
∙ ASM1074
▪ 4x USB 3.2 Gen 1 5Gbps Type-A ports available
through the internal connectors
∙ Hub-GL850G
▪ 4x USB 2.0 Type-A ports available through the internal
connectors
Audio
Realtek® ALC4082 Codec + ESS SABRE9018Q2C Combo
DAC/HPA
∙ 7.1-Channel High Definition Audio
∙ Supports S/PDIF output
LAN ∙ 2x Intel® I225V 2.5Gbps LAN controllers
Wireless LAN &
Bluetooth®
∙ Intel® Wi-Fi 6E
∙ The Wireless module is pre-installed in the M.2 (Key-E)
slot
∙ Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz*(160MHz)
up to 2.4Gbps
∙ Supports 802.11 a/ b/ g/ n/ ac/ ax
∙ Supports Bluetooth® 5.2**, FIPS, FISMA
* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in
Windows 10 build 21H1 and Windows 11.
** Bluetooth 5.2 will be ready in Windows 10 build 21H1 and Windows 11.
Continued on next column

MSI MEG Z690 ACE Specifications

General

Audio chip	Realtek ALC4082
Component for	PC
Motherboard chipset	Intel Z690
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Motherboard chipset family	Intel
Cables included	SATA
Drivers included	Yes
BIOS type	UEFI AMI
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	7
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
LAN controller	Intel I225-V
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Number of SATA III connectors	6
PCI Express x16 slots	3
Number of M.2 (M) slots	5
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Parallel processing technology support	CrossFire, SLI
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	6666, 4000, 5600 MHz
Processor socket	LGA 1700
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Harmonized System (HS) code	84733020
Weight	1000 g

Weight and Dimensions

Depth	277 mm
Width	305 mm
Height	90 mm
