Specifications
Continued from previous column
Internal Connectors
∙ 1x 24-pin ATX main power connector
∙ 2x 8-pin ATX 12V power connectors
∙ 6x SATA 6Gb/s connectors
∙ 5x M.2 slots (M-Key)
∙ 2x USB 3.2 Gen 2x2 20Gbps Type-C ports
∙ 2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4
USB 3.2 Gen 1 5Gbps ports)
∙ 2x USB 2.0 Type-A connectors (supports additional 4 USB
2.0 ports)
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin water-pump fan connector
∙ 6x 4-pin system fan connectors
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis Intrusion connector
∙ 1x 3-pin Water Flow connector
∙ 2x 2-pin Thermal sensor connectors
∙ 1x TPM module connector
∙ 1x Tuning Controller connector
Internal Buttons
∙ 1x Power button
∙ 1x Reset button
Jumpers
∙ 1x Clear CMOS jumper
∙ 1x Slow mode jumper
∙ 2x Low temperature booting jumpers
∙ 1x OC force enter BIOS jumper
LED Features
∙ 1x EZ LED Control switch
∙ 1x 4-pin RGB LED connector
∙ 2x 3-pin RAINBOW LED connectors
∙ 1x 3-pin CORSAIR LED connector
∙ 4x EZ Debug LED
∙ 1x 2-Digit Debug Code LED
Continued on next column

MSI MEG Z690 ACE Specifications

General

Audio chip	Realtek ALC4082
Component for	PC
Motherboard chipset	Intel Z690
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Motherboard chipset family	Intel
Cables included	SATA
Drivers included	Yes
BIOS type	UEFI AMI
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	7
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
LAN controller	Intel I225-V
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Number of SATA III connectors	6
PCI Express x16 slots	3
Number of M.2 (M) slots	5
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Parallel processing technology support	CrossFire, SLI
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	6666, 4000, 5600 MHz
Processor socket	LGA 1700
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Harmonized System (HS) code	84733020
Weight	1000 g

Weight and Dimensions

Depth	277 mm
Width	305 mm
Height	90 mm
