Overview of Components
3. Remove the protective films from the M.2 thermal pads on the M.2 plate.
3
4. If there is a screw installed on the M.2 plate, remove it first; otherwise, please
skip this step.
5. Secure the supplied M.2 standoff according to your M.2 SSD length.
4
5
Standoff
