Specifications
Continued from previous page
Back Panel
Connectors
∙ 1x Clear CMOS Button
∙ 1x Flash BIOS Button
∙ 1x PS/2 keyboard/ mouse combo port
∙ 2x USB 2.0 ports
∙ 3x USB 3.2 Gen 2 10Gbps Type-A ports
∙ 1x HDMI 2.1 with HDR port
∙ 4x USB 3.2 Gen 1 5Gbps Type-A ports
∙ 2x Wi-Fi Antenna connectors
∙ 1x LAN(RJ45) port
∙ 1x USB 3.2 Gen 2 10Gbps Type-C port
∙ 5x OFC audio jacks
∙ 1x Optical S/PDIF Out connector
Internal Connectors
∙ 1x 24-pin ATX main power connector
∙ 1x 8-pin ATX 12V power connector
∙ 1x 4-pin ATX 12V power connector
∙ 6x SATA 6Gb/s connectors
∙ 3x M.2 slots (M-Key)
∙ 2x USB 2.0 connectors (support additional 4 USB ports)
∙ 2x USB 3.2 Gen 1 5Gbps connectors (support additional 4
USB ports)
∙ 1x USB 3.2 Gen 2 10Gbps Type-C connector
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin water-pump connector
∙ 6x 4-pin system fan connectors
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x TPM module connector
∙ 1x Chassis Intrusion connector
∙ 1x 2-pin Thermal sensors connector
∙ 1x Tuning Controller connector
Jumpers
∙ 1x Clear CMOS jumper
∙ 1x Safe Boot jumper
Continued on next page
