Hardware Setup
2-17
Power Saving LED Connector: JGLED1
This allows you to connect to a power saving LED. The LED will be lit when
the system enters the suspend mode.
Power Saving Switch Connector: JGS1
Attach a power saving switch to this connector. Pressing the switch
once will have the system enter the sleep/suspend state. Press any key to wake
up the system.
JGS1
JGLED1
