MSI MS-7242 - Mainboard Specifications

MS-7242 Mainboard
1-2
Mainboard Specifications
Processor Support
- AMD Sempron/Athlon64/Athlon64 X2 AM2 processors in Socket 940
- Supports 3/4 pin CPU Fan with Fan Speed Control
- Supports up to 5000+ and higher CPU
Supported FSB
- 1000 MHz
Chipset
- North Bridge: ATI RS485/RS485C chipset (optional)
- South Bridge: ATI SB600 chipset
Memory Support
- DDRII 800/667/533/400 DRAM (8GB Max)
- 4 DIMMs DDRII (240pin / 1.8V)
LAN (Optional)
- Supports PCI LAN Realtek RTL8100C (10/100) or RTL8110SB/SC
(10/100/1000) Fast Ethermet (optional)
1394 (Optional)
- Supports 2 IEEE1394 ports, transfer rate is up to 400Mbps
- Controlled by VIA VT6307/VT6308 (optional)
Audio
- Realtek
®
ALC883/888 chip integrated (optional)
- Flexible 8-channel audio
- Compliant with High Definition Audio
IDE
- 1 IDE port by SB600
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
SATA
- SATA II ports by SB600
- Supports four SATA II device
- Supports storage and data transfers at up to 300MB/s
Floppy
- 1 floppy port
- Supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
