Gettng Started
AMD CrossFre™ (Mult-GPU) Technology
AMD CrossFre™ s a mult-GPU performance gamng platform. By lnkng together
two or more dscrete GPUs, CrossFre™ can sgn󰘰cant mprove system graphcs
performance. It allows the ablty to scale a system’s graphcs power as needed, makng t
the most scalable gamng platform. Ths manboard wll automatcally detect CrossFre™
technology and make changes n the BIOS as needed. Follow the nstructons below to
ensure a successful two-way CrossFre™ nstallaton.
Install two AMD Radeon™ HD graphcs cards nto the PCI_E1 & PCI_E2 expanson
slots.
Wth the two cards nstalled, two CrossFre™ Vdeo Lnk cable are requred to
connect the graphcs cards. Attach one sde of the cable on each of the cards
by way of the metal contacts (please refer to the pcture below). Please note that
although two graphcs cards have been nstalled, only the dsplay ports on the
graphcs card nstalled n the 󰘰rst PCIe x16 slot wll work. All dsplays should be
connected to ths graphcs card.
1.
2.
CrossFre
TM
Vdeo Lnk cable
Important
Please ensure that all graphcs cards used n CrossFre™ mode are of the same
brand and spec󰘰catons. For best compatblty wth the manboard, MSI graphcs
cards are recommended.
Make sure to connect an adequate power supply to the power connectors on the
graphcs cards to ensure stable operaton.
Only Wndows
®
XP wth Servce Pack 2 (SP2), Wndows™ XP Professonal x64
Edton, Wndows™ Vsta, & Wndows™ 7 wll support CrossFre™ mode.
•
•
•
