Français
39
Français
Merci d’avoir choisi une carte mère Mini-ITX de la série J750I/ J800I Series
(MS-7877 v.X). Les cartes mère de série J750I/ J800I est basée sur les
processeurs Intel
®
Celeron J750/ J800. La série J750I/ J800I délivrent de hautes
performances et la solution d’économie d’énergie pour BOX PC.
Schéma
Top: VGA Port
Bottom: DVI-D
SATA1 SATA2
T:
M:
B:
Line-In
Line-Out
Mic
USB3 .0 port
HDMI port
JPWR2
JTPM1
JPWR1
JBAT1 JCI1
JAUD1
PCI_E1
JUSB1
JFP1 JCOM1
CPUFAN
SYSFAN1
DIMM1
DIMM2
Top: LAN Jack
Bottom: USB 2.0 ports
Top : mouse
Bottom: keyboard
