Overview ▍
MS-91F7
1-3
Overview ▍
MS-91F7
Slot
1 PCI Express x16 slot (The PCIE4 slot supports up to PCIE x16 speed when
the PCIE3 slot is empty. When PCIE4 & PCIE3 slots are both occupied, the
supported speed will be PCIE x8 for each slot.)
3 PCI-Express x8 slots (The PCIE1 x8 slot supports x4 speed.)
1 32-bit/33MHz PCI slot
Dimension
12” x 10.2” SSI CEB form factor
Mounting
9 mounting holes
■
■
■
■
■
