MSI MS-91F7 - Quick Components Guide

2-2
Hardware Setup ▍
MS-91F7
Hardware Setup ▍
MS-91F7
Quick Components Guide
SYSFAN3,
p. 2-10
JPWR2, p. 2-8
DIMM Slots, p. 2-6
JPWR1, p. 2-8
CPUFAN1, p. 2-10
CPUFAN0,
p. 2-10
CPU, p. 2-3
DIMM Slots,
p. 2-6
JFP2, p. 2-12
PCI Slot, p. 2-16
PCI Express
Slots, p. 2-16
JUSB1~2, p. 2-11
JBWP1, p. 2-15
J_IPMB1, p. 2-13
JCOM2, p. 2-11
Rear Panel
I/O, p. 2-9
SYSFAN1, p. 2-10
JFP1, p. 2-12
JCI1, p. 2-13
JBOOT1, p. 2-15
SYSFAN2, p. 2-10
JBAT1, p. 2-14
SATA, p. 2-10
