2-13
Hardware Setup
▍
MS-91F7
Chassis Intrusion Switch Connector: JCI1
This connector connects to the chassis intrusion switch cable. If the chassis is
opened, the chassis intrusion mechanism will be activated. The system will re-
cord this status and show a warning message on the screen. To clear the warn-
ing, you must enter the BIOS utility and clear the record.
CINTRU
GND
IPMB Connector: J_IPMB1
This connector is used to connect the IPMB (Intelligent Platform Management
Bus) SMBus.
PIN SIGNAL
1
2
3
SMB_IPMB_5VSB_DAT
GND
SMB_IPMB_5VSB_CLK
1
