2
Line-Out Jack
This connector is provided for headphones or speakers.
3
Power Jack
The power adapter converts AC power to DC power for this jack.Power sup-
plied through this jack supplies power to the system.To prevent damage to
the system, always use the supplied power adapter.
4
USB 2�0 Port
The USB (Universal Serial Bus) port is for attaching USB devices such as
keyboard, mouse, or other USB-compatible devices.
5
Gigabit LAN Jack
The standard RJ-45 LAN jack is for connection to the Local Area Network
(LAN). You can connect a network cable to it.
6
HDMI Port
The High-Denition Multimedia Interface (HDMI) is an all-digital audio/video
interface capable of transmitting uncompressed streams. HDMI supports all
TV format, including standard, enhanced, or high-denition video, plus multi-
channel digital audio on a single cable.
7
VGA Port
The DB15-pin female connector is provided for monitor.
