MSI PRESTIGE X570 CREATION User Manual

17
Specifications
Continued from previous page
Storage
y 6x SATA 6Gb/s ports
 SATA1~SATA4 ports (from AMD
®
X570 Chipset)
 SATA5~SATA6 ports (from ASMedia ASM1061)
y 2x M.2 slots (Key M)*
 M2_1 slot (from AMD
®
Processor) supports PCIe
4.0 x4 (3rd Gen AMD Ryzen™) or PCIe 3.0 x4 (2nd Gen
AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics
and 2nd Gen AMD Ryzen™ with Radeon™ Graphics)
2242/2260/2280 storage devices
 M2_2 slot (from AMD
®
X570 Chipset) supports PCIe 4.0
x4 (3rd Gen AMD Ryzen™) or PCIe 3.0 x4 (2nd Gen AMD
Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd
Gen AMD Ryzen™ with Radeon™ Graphics) and SATA
6Gb/s 2242/ 2260/ 2280/ 22110 storage devices
*The speeds may vary for different devices
RAID
y Supports RAID 0, RAID 1 and RAID 10 for X570 Chipset
SATA storage devices
y Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe
storage devices
LAN
y 1x Intel
®
I211AT Gigabit LAN controller
y 1x Aquantia
®
AQC107 10-Gigabit LAN controller
WiFi & Bluetooth
Intel
®
Wi-Fi 6 AX200
y The Wireless module is pre-install in the M2_WIFI1 (Key-E) slot
y Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-
5GHz (160MHz) up to 2.4Gbps
y Supports Bluetooth
®
5
USB
y AMD
®
X570 Chipset
 1x USB 3.2 Gen2 (SuperSpeed USB 10Gbps) Type-C
internal connector
 12x USB 3.2 Gen1 (SuperSpeed USB) ports (8 Type-A
ports on the back panel, 4 ports available through the
internal USB 3.2 Gen1 connectors)
 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on
the back panel, 4 ports available through the internal
USB 2.0 connectors)
y AMD
®
Processor
 2x USB 3.2 Gen2 (3rd Gen AMD Ryzen™) or USB 3.2
Gen1 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™
Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™
Graphics) Type-A and Type-C port on the back panel
 2x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the
back panel
Continued on next page
Downloaded from ManualsNet.com search engine

MSI PRESTIGE X570 CREATION Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
Audio chip	Realtek ALC1220
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Number of mounting holes	9
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64, Windows 7 Enterprise x64, Windows 7 Home Basic x64, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate x64, Windows 7 x64
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600, 4733, 4800, 5000 MHz
Number of M.2 (M) slots	2
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA III
DirectX version	12.0
Parallel processing technology support	2-Way CrossFireX, 3-Way CrossFireX
Number of SATA III connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
BIOS type	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
LAN controller	Intel® I211-AT
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
Ethernet interface type	10 Gigabit Ethernet, Gigabit Ethernet
Cables included	SATA

Weight and Dimensions

Depth	272 mm
Width	305 mm
