AMD RAID Conﬁguration

Installing RAID Driver

New Operating System Installation

The following details the installation of the drivers while installing operating system.

1. During the operating system installation, after selecting the location to install

Windows click on Load driver button to install a third party RAID driver.

2. When prompted, insert the USB flash drive with AMD RAID Drivers and then click

Browse.

 To make an AMD RAID Drivers USB flash drive. Insert the MSI Driver Disc into

the optical drive. Copy all the contents in \\Storage\AMD\AMD\Packages\Drivers\

SBDrv\RAID_NVMe

3. Navigate to the directory containing the saved AMD RAID drivers, then click OK.

4. Select the (rcbottom.inf) driver, click Next.

5. When prompted, click OK.

6. Click Browse and navigate to the directory containing the saved AMD RAID drivers

again, then click OK.

7. Select the (rcraid.inf) driver, click Next.

8. You have successfully installed the RAID driver, and Windows setup should

continue.

9. Leave the disk/ USB drive in the computer until the system reboots itself. Windows

setup will need to copy the files after the RAID volume is formatted, and Windows

setup starts copying files.

AMD RAIDXpert2 Management Suite Installation

1. Set the SATA Mode to RAID Mode in BIOS

2. Insert the MSI Driver Disc into the optical drive.

3. Click the Select to choose what happens with this disc pop-up notification, then

select Run DVDSetup.exe to open the installer. If you turn off the AutoPlay feature

from the Windows Control Panel, you can still manually execute the DVDSetup.exe

from the root path of the MSI Driver Disc.

4. Under the Drivers/Software tab, check the AMD RAID Drivers check-box.

5. Click the Install button.

6. When prompt you to restart, click OK button to finish.

7. Restart your computer and enter the Windows operating system.

8. Double-click the RAIDXpert2 icon to open the RAIDXpert2 Web GUI.

 Default credentials are:

 Username - admin

 Password - admin

9. Change the credentials:

 Create new username and password

10. Re-log into the RAIDXpert2 Web GUI with the new credentials.

Downloaded from ManualsNet.com search engine
