M2_1~2: M.2 Slots (Key M)
M2_1
M2_2
Important
If your M.2 SSD equips its own heatsink, please remove the M.2 rubber cube in the
M.2 slot before installing M.2 SSD. Do not re-install the heatsink supplied with your
motherboard.
Installing M.2 module into M2_1 slot
1. Loosen the screws of M.2 SHIELD FROZR heatsink.
2. Remove the M.2 SHIELD FROZR and remove the protective films from the thermal
pads
11
11
22
