MSI X399 SLI PLUS

29
Overview of Components
GAME BOOST knob
0
1
2
4
6
8
1
0
1
1
OC1: GAME BOOST Knob
This knob allows you to manually select a stage from number 0 (default) to number 11
(extreme) for overclocking the processor. The processor’s voltage and frequency will
be automatically adjusted after you power on your computer.
Using GAME BOOST Knob
To setup the GAME BOOST knob, take the following steps:
1. Set the GAME BOOST knob to hardware mode in BIOS Setup.
2. Power off the computer.
3. Rotate the GAME BOOST knob to select the overclocking stage as you desire.
Stage
CPU Frequency
TR 1950X TR 1920X TR 1920 TR 1900X
0 3.4 GHz 3.5 GHz 3.2 GHz 3.8 GHz
1 3.75 GHz 3.85 GHz 3.55 GHz 4.15 GHz
2 3.8 GHz 3.9 GHz 3.6 GHz 4.2 GHz
4 3.85 GHz 3.95 GHz 3.65 GHz 4.25 GHz
6 3.9 GHz 4 GHz 3.7 GHz 4.3 GHz
8 3.95 GHz 4.05 GHz 3.75 GHz 4.35 GHz
10 4 GHz 4.1 GHz 3.8 GHz 4.4 GHz
11 4.1 GHz 4.2 GHz 3.9 GHz 4.5 GHz
4. Power on and then GAME BOOST will automatically overclock processor depending
on the stage you selected.
To disable GAME BOOST:
1. Set the GAME BOOST knob to HW mode in BIOS Setup.
2. Power off the computer.
3. Rotate the GAME BOOST knob to 0 and then power on. The configuration
parameters will be returned to default values.
Important
y You can also control the GAME BOOST function in BIOS Setup or with MSI COMMAND
CENTER software.
y In order to optimize performance and improve system stability, when you activate the
GAME BOOST function, please leave the settings in the BIOS > OC menu unchanged.
