32
Overview of Components
Important
y
Always insert a memory module in the DIMMB2 slot first.
y
To ensure system stability for Dual/ Triple/ Quad channel mode, memory modules
must be of the same type, number and density.
y
Due to chipset resource usage, the available capacity of memory will be a little less
than the amount of installed.
y
The Memory DIMM voltage below 1.35V is suggested to protect the CPU.
y
Please note that the maximum capacity of addressable memory is 4GB or less
for 32-bit Windows OS due to the memory address limitation. Therefore, we
recommended that you to install 64-bit Windows OS if you want to install more than
4GB memory on the motherboard.
y
It is recommended to use a more efficient memory cooling system for full DIMMs
installation or overclocking.
y
The stability and compatibility of installed memory modules depend on installed CPU
and devices when overclocking.
DIMMA2
DIMMA2
DIMMA1
DIMMB2
DIMMB2
DIMMB1
DIMMC2
DIMMC2
DIMMC1
DIMMD1
DIMMD2
DIMMD2
